objacces.h File Reference

#include <applicfg.h>

Go to the source code of this file.

Macros
#define	getODentry(OD, wIndex, bSubindex, pDestData, pExpectedSize, pDataType, checkAccess)
#define	readLocalDict(OD, wIndex, bSubindex, pDestData, pExpectedSize, pDataType, checkAccess)
#define	setODentry(d, wIndex, bSubindex, pSourceData, pExpectedSize, checkAccess)
#define	writeLocalDict(d, wIndex, bSubindex, pSourceData, pExpectedSize, checkAccess)

Typedefs
typedef UNS32(*	valueRangeTest_t) (UNS8 typeValue, void *Value)
typedef void(*	storeODSubIndex_t) (CO_Data *d, UNS16 wIndex, UNS8 bSubindex)

Functions
void	_storeODSubIndex (CO_Data *d, UNS16 wIndex, UNS8 bSubindex)
	<BRIEF>
UNS8	accessDictionaryError (UNS16 index, UNS8 subIndex, UNS32 sizeDataDict, UNS32 sizeDataGiven, UNS32 code)
UNS32	_getODentry (CO_Data *d, UNS16 wIndex, UNS8 bSubindex, void *pDestData, UNS32 *pExpectedSize, UNS8 *pDataType, UNS8 checkAccess, UNS8 endianize)
	_getODentry() Reads an entry from the object dictionary.
UNS32	_setODentry (CO_Data *d, UNS16 wIndex, UNS8 bSubindex, void *pSourceData, UNS32 *pExpectedSize, UNS8 checkAccess, UNS8 endianize)
	By this function you can write an entry into the object dictionary.
const indextable *	scanIndexOD (CO_Data *d, UNS16 wIndex, UNS32 *errorCode, ODCallback_t **Callback)
	Scan the index of object dictionary. Used only by setODentry and getODentry.
UNS32	RegisterSetODentryCallBack (CO_Data *d, UNS16 wIndex, UNS8 bSubindex, ODCallback_t Callback)
	<BRIEF>

Detailed Description

Created on: Oct 9, 2024 Author: jenej

Definition in file objacces.h.

Macro Definition Documentation

getODentry

#define getODentry	(		OD,
			wIndex,
			bSubindex,
			pDestData,
			pExpectedSize,
			pDataType,
			checkAccess )

Value:

       _getODentry( OD, wIndex, bSubindex, pDestData, pExpectedSize, \
                  pDataType,  checkAccess, 1)

Definition at line 32 of file objacces.h.

readLocalDict

#define readLocalDict	(		OD,
			wIndex,
			bSubindex,
			pDestData,
			pExpectedSize,
			pDataType,
			checkAccess )

Value:

       _getODentry( OD, wIndex, bSubindex, pDestData, pExpectedSize, \
                  pDataType,  checkAccess, 0)

Definition at line 37 of file objacces.h.

setODentry

#define setODentry	(		d,
			wIndex,
			bSubindex,
			pSourceData,
			pExpectedSize,
			checkAccess )

Value:

       _setODentry( d, wIndex, bSubindex, pSourceData, pExpectedSize, \
                  checkAccess, 1)

Definition at line 52 of file objacces.h.

writeLocalDict

#define writeLocalDict	(		d,
			wIndex,
			bSubindex,
			pSourceData,
			pExpectedSize,
			checkAccess )

Value:

       _setODentry( d, wIndex, bSubindex, pSourceData, pExpectedSize, checkAccess, 0)

Definition at line 57 of file objacces.h.

Typedef Documentation

storeODSubIndex_t

typedef void(* storeODSubIndex_t) (CO_Data *d, UNS16 wIndex, UNS8 bSubindex)

Definition at line 14 of file objacces.h.

valueRangeTest_t

typedef UNS32(* valueRangeTest_t) (UNS8 typeValue, void *Value)

Definition at line 13 of file objacces.h.

Function Documentation

_getODentry()

UNS32 _getODentry	(	CO_Data *	d,
		UNS16	wIndex,
		UNS8	bSubindex,
		void *	pDestData,
		UNS32 *	pExpectedSize,
		UNS8 *	pDataType,
		UNS8	checkAccess,
		UNS8	endianize )

_getODentry() Reads an entry from the object dictionary.

use getODentry() macro to read from object and endianize use readLocalDict() macro to read from object and not endianize

// Example usage:
UNS8  *pbData;
UNS8 length;
UNS32 returnValue;

returnValue = getODentry( (UNS16)0x100B, (UNS8)1,
(void * *)&pbData, (UNS8 *)&length );
if( returnValue != SUCCESSFUL )
{
    // error handling
}

Parameters

*d	Pointer to a CAN object data structure
wIndex	The index in the object dictionary where you want to read an entry
bSubindex	The subindex of the Index. e.g. mostly subindex 0 is used to tell you how many valid entries you can find in this index. Look at the canopen standard for further information
*pDestData	Pointer to the pointer which points to the variable where the value of this object dictionary entry should be copied
*pExpectedSize	This function writes the size of the copied value (in Byte) into this variable.
*pDataType	Pointer to the type of the data. See objdictdef.h
CheckAccess	if other than 0, do not read if the data is Write Only [Not used today. Put always 0].
Endianize	When not 0, data is endianized into network byte order when 0, data is not endianized and copied in machine native endianness

Returns

• OD_SUCCESSFUL is returned upon success.
• SDO abort code is returned if error occurs . (See file def.h)

Definition at line 111 of file objacces.c.

_setODentry()

UNS32 _setODentry	(	CO_Data *	d,
		UNS16	wIndex,
		UNS8	bSubindex,
		void *	pSourceData,
		UNS32 *	pExpectedSize,
		UNS8	checkAccess,
		UNS8	endianize )

By this function you can write an entry into the object dictionary.

Parameters

*d	Pointer to a CAN object data structure
wIndex	The index in the object dictionary where you want to write an entry
bSubindex	The subindex of the Index. e.g. mostly subindex 0 is used to tell you how many valid entries you can find in this index. Look at the canopen standard for further information
*pSourceData	Pointer to the variable that holds the value that should be copied into the object dictionary
*pExpectedSize	The size of the value (in Byte).
checkAccess	Flag that indicate if a check rights must be perfomed (0 : no , other than 0 : yes)
endianize	When not 0, data is endianized into network byte order when 0, data is not endianized and copied in machine native endianness

Returns

• OD_SUCCESSFUL is returned upon success.
• SDO abort code is returned if error occurs . (See file def.h)

Definition at line 235 of file objacces.c.

scanIndexOD()

const indextable * scanIndexOD	(	CO_Data *	d,
		UNS16	wIndex,
		UNS32 *	errorCode,
		ODCallback_t **	Callback )

Scan the index of object dictionary. Used only by setODentry and getODentry.

Parameters

*d	Pointer to a CAN object data structure
wIndex
*errorCode	: OD_SUCCESSFUL if index foundor SDO abort code. (See file def.h)
**Callback

Returns

NULL if index not found. Else : return the table part of the object dictionary.

Definition at line 343 of file objacces.c.

Referenced by PDOInit(), and RegisterSetODentryCallBack().

Here is the caller graph for this function:
